Main Performance:
Max Lifting Capacity: 8500kg
Max Boom Length: 26m
Max Gradeability: 35%
Max Traveling Speed: 89km/h
Wheel Base: 4400mm
Overall Dimension: 9675(9725)mm×2400mm×3250(3260)mm
Outrigger Span((Longitudinal): 4650mm
Outrigger Span(Transverse): 5100mm
Compatible with Chassis:
Engine Model: Yuchai YCS04160-68
Chassis: Dongfeng & Dongfeng Vasol T3
Transmission: FAST 8-speed forward
